C-PLY
Birch film faced formwork plywood
Film Faced Formwork Plywood
GALERASHigh-ply pine formwork plywood
GALERAS is our strongest pine formwork panel, with a 13–15 ply pine core. Its phenolic film face makes it water resistant and suitable for repeated use.
- Phone+90 364 235 01 32
- E-mailsales@akcaplywood.com
GALERAS18 – 21 mm
01Technical specifications
| Wood species | Pine |
|---|---|
| Glue | WBP (weather & boil proof, phenolic) |
| Thickness | 18 – 21 mm |
| Plies | 13 – 15 plies |
| Dimensions | 2500 × 1250 · 2440 × 1220 · 3000 × 1500 · 3000 × 1250 mm |
| Face | Phenolic film (125 g/m²) — black, brown, dark brown |
| Edge sealing | Acrylic waterproof paint |
| Density | 550–660 kg/m³ |
| Tolerance | ± 0,5 mm |
02Applications
- 01Concrete formwork systems
- 02Building and infrastructure projects
- 03Bridges, tunnels and shear walls
- 04Outdoor applications
03Film print
GALERAS film face
The product’s own logo is printed diagonally across the phenolic film face, so the panel is recognisable at a glance on site.
Move your cursor over the panel to catch the light
03Get a Quote
Request a quote for this product
Send us the thickness, size and quantity you need — our sales team will respond shortly.
